Pellet Feed Plants

Economic Type Mini Pellet Feed Plant

Why Pellet Feed?

  • The main purpose of compressing of powder feeds is to eliminate some problems in powder feeds consumed.
  • Powder feeds intermingle with the air in the powder form during consumption and cause some lung and respiratory problems for the animals.
  • Besides, powder feeds are consumed by the animals reluctantly because of their scent.
  • On the other hand, the pellet feed is consumed by the animals tastefully due to its flavour and preferable scent.

Advantages of Pellet Feed

  • High digestibility
  • The decrease in the feed loss caused by the consuming habits of the animals
  • Feeds consumed by the animals are absorbed more in the intestines than in the rumen.
  • Higher milk yield
  • Higher meat production efficiency of the stocks in a shorter time
  • The warehousing cost is decreased and the durability is increased
  • Longer storage time
  • The formation of bacteria and fungus is at minimum level.

Area of Usage

  • Cattle and small cattle milk feed
  • Poultry feeds
  • Fish feeds
  • Pomace pelletizing (olive-oil residue)
  • All grain groups
  • Straw and clover

Technicial Specifications

Economic Type Mini Pellet Feed Plant

Weighing and Feed Loading Unit
Supply Bunker Capacity 250 - 500 kg
Weighing Capacity 1.000 kg
Weigher Panel Digital
Helix Motor Power 1,5 hp,250d/dk,380v
Dimensions (W x L x H) 125 x 125 x 270 cm
Weight 185 kg
Breaker - Mixer and Sack Fill Unit
Breaking and Mixing Capacity 750-1.000 kg/h
Breaking and Mixing Capacity 1.030-2.750 kg/h
Mixing Time 3,5 min.
Mixing Capacity 800 lt
Sack Fill Time
22 s
Breaking Motor Power  15 hp, 380v
Mixing Motor Powe
10 hp, 380v
Sack Fill Motor Powe
1,5 hp, 380v
Weight 920 kg
Dimensions (W x L x H) 137 x 277 x 205
Number of Blade
36 piece
Feed Loading Unit
Motor Power 11,5 hp, 380v
Feed Bunker Capacity
900 lt
145 kg
Loading Height 290 kg
Dimensions  (W x L x H) 110 x 295 x 320 cm
Pelletizing Unit
Motor Powe
22-30 kW
Pelletizing Capacity (8 mm disc)
300-500 kg/h

**Produced based on the capacity needs between 250 kg/h – 1500 kg/h

**Boiler and conditioner are optional.
